AC-800LB2 Car light camera with night vision function, built-in 8 white light beads, LED lamp board power 24W, infrared distance up to 30-50m, even at night driving can provide drivers with a clear and bright vision. The camera has a viewing angle of 155°, wide viewing range, high visibility, supporting high-speed, long-distance, and real-time transmission. The wide visual range is unobstructed, which helps driving safety.
Support ICR switch
Support mirror switch
Waterproof grade IP69K
With night vision function
| Image Sensor |
1/3 AR0130 |
| TV System |
NTSC/PAL |
| Effective Pixels |
1280（H）ⅹ960（V） |
| Sensing Area |
3.75μm |
| Sync. System |
Internal |
| Resolution |
130W |
| Minimum Illumination |
0.1 Lux (day), 0 Lux (with IR) |
| IR LED Qty |
white light*8PCS |
| Light type |
60° floodlight |
| Night vision distance |
30-50m |
| Microphone |
NO |
| Video Output |
1.0 Vp-p/75 Ohm |
| Scanning System |
interlace |
| AGC |
AUTO |
| Signal to noise ratio |
Better than 48dB |
| White balance |
AUTO |
| Gamma Consumption |
0.45 |
| Electronic Shutter |
AUTO |
| Backlight Compensation |
AUTO |
| Lens |
1.7mm |
| Lens angle |
140° |
| LED lamp plate voltage |
DC12-24V |
| LED lamp board power |
24W |
| Luminous flux / lumen |
1154/lm |
| Color temperature |
6000K |
| Lens material |
PC |
| Power Supply |
DC12V |
| Current Drain |
70±5mA (day)/2.33±5A(night vision) |
| Operating Temperature |
-20℃-70℃,RH 95% MAX |
| Storage Temperature |
-30℃-80℃,RH 95% MAX |
